630 Ventilation Outlet

630 Ventilation Outlet for Construction – Technical Specification

1. Core Parameters

• Industry: Construction

• Product Name: 630 Ventilation Outlet

• Material: Aluminum Alloy (6063)

• Wall Thickness: 2.0 mm

• Surface Finish: Wiredrawing

• Dimensions: Ø615 mm × H373 mm

• Dimensional Tolerance: Conforms to GB/T 1804-2000, mm-level precision

• Surface Roughness: Ra ≤ 0.8 μm after wiredrawing


2. Manufacturing Process

• Core Processing Method: CNC metal spinning forming combined with wiredrawing finishing, followed by secondary machining for precision. Equipment includes CNC metal spinning lathe and fully automatic wiredrawing machine.

  • CNC spinning spindle speed: 1000–1500 r/min

  • Roller feed rate: 8–12 mm/s

  • Single pass deformation: 0.3–0.5 mm

  • Wall thickness uniformity deviation: ≤ ±0.08 mm

  • Wiredrawing: axial direction, 15–20 m/min, belt grit 1200#

• Raw Material Preparation: 6063 aluminum alloy sheets undergo alkaline degreasing (50–60°C, NaOH 4–6%, 8–12 min), water neutralization, drying (80–100°C, 15–20 min), and flattening (flatness deviation ≤0.2 mm/m) to remove oil, oxide scale, and surface scratches.

• CNC Process Control: CNC metal spinning lathe with G-code programming defines spinning paths. Real-time diameter and height data acquisition at 12 Hz for closed-loop control:
  • Ø615 mm tolerance ≤ ±0.4 mm
  • H373 mm tolerance ≤ ±0.3 mm
  • End faces precision-turned on CNC lathe; perpendicularity error ≤ 0.1 mm

• Post-Processing: Mechanical deburring at 3200 r/min with 1500# abrasive wheel. Compressed air cleaning removes residual debris, followed by dimensional recheck and surface quality inspection per core parameters.


3. Quality Control

• Standards: ISO 9001:2015 quality management system, GB/T 3880.1-2012 aluminum building profiles standard. Full-process quality control from raw material intake to finished product delivery.

• Raw Material Inspection:

  • Spectrometer analysis: element deviation ≤ ±0.05% (Mg 0.45–0.9%, Si 0.2–0.6%)

  • Hardness test: ≥60 HB

  • Surface check: visual + 20× magnifier, no cracks, inclusions, dents

• Process Inspection:

  • Spinning Form Accuracy: curvature template, adherence ≥98%

  • Dimensional Inspection: CMM (±0.005 mm) for Ø615 mm, H373 mm, 2.0 mm thickness

  • Wiredrawing Inspection: visual uniformity, Ra measured with roughness tester

  • Edge Inspection: no burrs, sharp edges; chamfer R ≥ 1.5 mm

• Final Inspection: Sampling per GB/T 2828.1-2012, AQL 2.5. Items include dimensional verification, material recheck, surface, appearance, and assembly fit. Products are tagged with traceability codes including raw material batch, equipment, and inspector information.


4. Production Capacity & Delivery

• Capacity: 5 CNC spinning lathes, 3 wiredrawing machines, 2 CNC lathes in production line. Daily output: 60 pcs per line (2 shifts, 8h each), max monthly output: 3600 pcs. Supports parallel multi-equipment production for large projects.

• Production Lead Time:

  • Small batch (10–50 pcs): 5–8 working days

  • Large batch (≥100 pcs): 10–15 working days

  • Urgent orders: 3–5 working days (schedule adjusted)

• Delivery: Packed with pearl cotton + cardboard + wooden pallet (50 pcs/pallet). Domestic logistics 2–7 days depending on region; on-site construction delivery available with 3-day advance notice.

• Customization: Sizes Ø300–1000 mm, H150–600 mm; surface finish options (anodizing, coating). Requires client installation parameters and appearance requirements. Feasibility review: 2 working days.


5. Application Scenarios

• Core Application: Integrated into building HVAC systems for indoor and outdoor ventilation, mounted on walls, rooftops, basements, or equipment rooms, ensuring airflow and exhaust of indoor air.

• Operating Conditions:

  • Temperature: -40°C to 80°C (6063 aluminum alloy)

  • Medium: air and non-corrosive building exhaust gases

  • Building Types: commercial complexes, offices, residential, industrial, hospitals, schools

• Interface Requirements: Must match Ø615 mm × H373 mm. Supports duct connection customization; client provides duct dimensions and installation details.


6. Extended Application Scenarios

1. Fire Smoke Ventilation Systems: Acts as smoke outlet, aluminum withstands high temperature, ensures rapid smoke evacuation during fire.

2. Cleanroom Ventilation: Provides dust-free airflow, wiredrawing surface resists dust accumulation, easy cleaning.

3. Parking Garage Ventilation: Handles high airflow, humid environment; corrosion-resistant aluminum.

4. BIPV Integrated Ventilation: Supports building-integrated photovoltaics ventilation, combines energy efficiency with airflow.


7. After-Sales Service

1. Warranty: 24 months from acceptance; covers dimensional deviation, material defects, surface finish issues, improper installation. Free replacement or repair; shipping and on-site costs covered.

2. Technical Support: Pre-sale selection consultation, installation manuals, CNC diagrams, phone/video guidance, on-site installation support for large orders.

3. Feedback & Response: 24h response to inquiries, 1–3 working days solution. Dedicated personnel ensure closed-loop quality follow-up.

4. Post-Warranty Services: Paid repair, replacement, refurbishing (e.g., wiredrawing surface restoration). Optional long-term maintenance agreements with annual inspections (1–2 times/year) and maintenance advice.
